Low noise No vibration Rotary Drum Screen Machine for Water treatment
Product Details:
| Place of Origin: | China |
| Brand Name: | CHENENG |
| Certification: | CE/ISO |
| Model Number: | CSM |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1pcs |
|---|---|
| Price: | negotiation |
| Packaging Details: | nude packing, bulk packed in wooden cases |
| Delivery Time: | 30 working days after received your payment |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 10pcs per month |
|
Detail Information |
|||
| Product Name: | Drum Screen | Application: | Water Treatment |
|---|---|---|---|
| Material: | CS Or SS | Standard: | ISO |
| Capacity: | 8-912m³/h | Structure: | Compact Connection |
| High Light: | water purification screening,rotary bar screen |
||
Product Description
Low noise No vibration Rotary Drum Screen Machine for Water treatment
Specifications:
|
Model |
Capacity(m³/h) |
Drum diameter(mm) |
Drum length (mm) |
Motor power(kw) |
|
CSM-3560 |
8~42 |
350 |
600 |
0.25 |
|
CSM-610 |
33~170 |
610 |
610 |
0.55 |
|
CSM-1220 |
65~340 |
610 |
1220 |
0.55 |
|
CSM-1830 |
100~520 |
610 |
1830 |
0.75 |
|
CSM-81830 |
175~912 |
800 |
1830 |
1.1 |
Product Description
Drum sieve has simple structure and running Smoothly ,bolting reliable And equipped
with a screen cleaning device.It has Large production capacity and easy to repair.According to
the mesh size can bescreed sectionalized.
It is suitable for sieving various properties of material,And some moist,easy to blocking material
such as the coal, coal gangue and coke raw lime. The Products maximum 100mm,Intermediate
10-50mm,The fine could reach 1.5mm, the products are well received by consumers.
Production Features
1. It adopts Rolling conveying principle,small friction coefficient,Wear light,Very little mesh
blocked.
2. Idler adopts The whole shaft structure, operation Smoothly,No vibration and Low noise.
3. Internal drum screen sieve parts adopts split design,Simple structure,Fast and convenient
to replacement or repair.
