Self-cleaning Solid Liquid Separation Static Screen in Waste Water Treatment Plants
Product Details:
| Place of Origin: | China |
| Brand Name: | CHENENG |
| Certification: | CE/ISO |
| Model Number: | CHS |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1pcs |
|---|---|
| Price: | negotiation |
| Packaging Details: | nude packing, bulk packed in wooden cases |
| Delivery Time: | 15 working days after received your payment |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 20 pcs per month |
|
Detail Information |
|||
| Product Name: | Static Screen | Application: | Water Treatment |
|---|---|---|---|
| Material: | CS Or SS | Standard: | ISO |
| Capacity: | 9-160m³/h | Structure: | Compact Connection |
| High Light: | rotary bar screen,solid liquid separation equipment |
||
Product Description
Self-cleaning Solid Liquid Separation Static Screen in Waste Water Treatment Plants
Principle of Static Sieve
The cheneng static sieve CHS is a filter used in solid-liquid separation in Waste Water Treatment Plants. It is a self-cleaning fine screen which can produce a filtration level screening quality, operating by gravity without the need for actuating equipment.
Advantages
1. Sieve screen is offered with apertures from 0.5 mm to 1.5 mm;
2. Passive filtration method maximizes solids removal;
3. No moving parts, easy to set up with small installation area;
4. Self-cleaning, easy to maintain, and the running cost is zero;
5. No actuating equipment, neither vibration nor noise is produced;
6. Simple structure, operation simplicity, sturdiness;
7. Fine screenings.
Application
Static sieves HS have many applications in the pretreatment of waste water for practically any kind of industry. Performance is optimum in those applications where there is no oil, a dryness greater than that obtained even by rotary screens being achieved with this system.
1. The screening of water from the plastics, paper, textile, tanning, laundry , milk industries and food industries etc…
2. Tank cleaning.
3. Screening of solids after channel bar screening in urban water cleaning.
4. Recycling of water in cleaning circuits.
Specifications:
|
Model |
Capacity (m³/h) |
Screen width (mm) |
Net weight (kg) |
Operating weight (kg) |
|
CHS-60 |
9~60 |
600 |
280 |
980 |
|
CHS-90 |
12~80 |
900 |
350 |
1300 |
|
CHS-120 |
18~100 |
1200 |
460 |
1950 |
|
CHS-150 |
22~130 |
1500 |
530 |
2350 |
|
CHS-200 |
28~160 |
2000 |
690 |
3170 |
