CSM drum type spiral screen , grit screen for sewage wastewater treatment
Product Details:
| Place of Origin: | China |
| Brand Name: | CHENENG |
| Certification: | CE/ISO |
| Model Number: | CSM |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1pcs |
|---|---|
| Price: | negotiation |
| Packaging Details: | nude packing, bulk packed in wooden cases |
| Delivery Time: | 30 working days after received your payment |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 10pcs per month |
|
Detail Information |
|||
| Product Name: | Drum Screen | Application: | Water Treatment |
|---|---|---|---|
| Material: | CS Or SS | Standard: | ISO |
| Capacity: | 8-912m³/h | Structure: | Compact Connection |
| High Light: | water purification screening,rotary bar screen |
||
Product Description
CSM drum type spiral screen , grit screen for sewage wastewater treatment
Specifications:
|
Model |
Capacity(m³/h) |
Drum diameter(mm) |
Drum length (mm) |
Motor power(kw) |
|
CSM-3560 |
8~42 |
350 |
600 |
0.25 |
|
CSM-610 |
33~170 |
610 |
610 |
0.55 |
|
CSM-1220 |
65~340 |
610 |
1220 |
0.55 |
|
CSM-1830 |
100~520 |
610 |
1830 |
0.75 |
|
CSM-81830 |
175~912 |
800 |
1830 |
1.1 |
Description:
The CSM drum screen handles difficult solids, including scum, oily and greasy materials in municipal and industrial applications. Opening sizes are available from 0.25mm to 2.5mm. Capacities range from 8m³/h to 912m³/h in a single unit. Additional models are available to handle higher capacities.
The CSM drum screen features a heavy-duty corrosion-resistant stainless chassis and wedgewire screening cylinder. Incoming flow is directed under a baffle to dampen forward velocity and insure even loading over the length of the screen cylinder. The natural action of wastewater cascading through the screen creates a powerful backwash which results in a continuously clean surface. Solids are caught on the outsider of the screen surface and are removed by a tensioned doctor blade.
All CSM units have an internal spray bar available. This spray bar is positioned within inches of the surface of the cylinder and benefits greasy applications or applications requiring small size screen openings.
Applications:
1. Municipal sewage
2. Abattoirs
3. Cheese processing
4. Container washing
5. Dairies
6. Food processing
7. Fish processing
8. Metal removal
9. Meat industry
10. Poultry processing
11. Pulp& paper
12. Small goods
13. Tanneries
14. Vegetable industries
Competitive Advantage:
1. Simple structure with high reliability.
2. Rotating drum is made of wedge wire with best hydraulic performance.
3. Available in 304 or 316 stainless steel.
4. Horizontally mounted cylinder has external bearings to simplify maintenance.
5. Corrosion-resistant stainless steel construction.
