Large Throughput Horizontal Sludge Dewatering Equipment With Solid liquid Separation
Product Details:
| Place of Origin: | China |
| Brand Name: | CHENENG |
| Certification: | CE/ISO |
| Model Number: | CDJ |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1pcs |
|---|---|
| Price: | negotiation |
| Packaging Details: | nude packing, bulk packed in wooden cases |
| Delivery Time: | 30 working days after received your payment |
| Supply Ability: | 15pcs per month |
|
Detail Information |
|||
| Product Name: | Belt Press Filter | Application: | Water Treatment |
|---|---|---|---|
| Material: | CS Or SS | Standard: | ISO |
| Structure: | Compact Connection | ||
| High Light: | dewatering screw press machine,sludge removal equipment |
||
Product Description
Large Throughput Horizontal Belt Filter Press Price With Solid liquid Separation
Application
Mainly used in sludge dewatering of municipal wastewater treatment plant and industrial wastewater treatment plant.
Advantage
- Efficient drum structure,single drum,double drum or three drum configuration can meet the press part solid load,having drier sludge cake.
- Precise structure technology:frame is fabricated with thick steel plate by laser cutting,advanced manufacturing process ensure all the roll shaft operate in high precision,filter cloth operate smoothly,low wear rate.
- Pneumatic variable correction technology:special designed detector can correct the filter cloth with minimum radius,make the filter cloth operate smoothly all the time.
- Pneumatic steady pressure tension system:Pneumatic jack steady pressure tension system,realize the machine high stability and high dewatering efficiency.
- Modified roll system:Through continuous improvement,new roll shaft manufacture craft can adjust all kinds of extreme operating conditions,coordinate with high quality bearing,can operate reliably for long time.
| Model | CDJ 1200 | CDJ 1600 | CDJ 2000 |
| Press part filter belt cloth width(mm) | 1200 | 1600 | 2000 |
| Concentration drum spec(mm) | φ800*2000 | φ800*2000 | φ800*2000(2sets) |
| Drum speed(r/min) | 2-9 | ||
| Concentration drive power(kw) | 0.55 | 0.55 | 0.55*2 |
| Press drive power(kw) | 0.55 | 1.1 | 1.5 |
| Capacity(Dry sludge kg/m filter belt cloth·h) | 160-200 | ||
| Sludge moisture content | ≤80(Municipal sludqe) | ||
| Sludge inlet pipe diameter | DN80 | DN80 | DN80*2 |
| Backwash pipe diameter | DN40 | ||
| Backwash water flow rate(m3/h) | 15 | 18 | 24 |
| Backwash pump head(m) | 70-80 | ||
