High capacity mixing chamber chemical dosing system and polymer preparation unit
Product Details:
| Place of Origin: | China |
| Brand Name: | CHENENG |
| Certification: | CE/ISO |
| Model Number: | CPD |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1pcs |
|---|---|
| Price: | negotiation |
| Packaging Details: | nude packing, bulk packed in wooden cases |
| Delivery Time: | 20 working days after received your payment |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 10pcs per month |
|
Detail Information |
|||
| Product Name: | Chemical Dosing Equipment | Application: | Water Treatment |
|---|---|---|---|
| Material: | CS Or SS | Standard: | ISO |
| Capacity: | 200-10940L/h | Structure: | Compact Connection |
| High Light: | polymer preparation unit,chemical dosing equipment |
||
Product Description
High capacity mixing chamber chemical dosing system and polymer preparation unit
Specifications:
|
Model |
PT200 |
PT430 |
PT958 |
PT1340 |
PT2660 |
PT4165 |
PT6660 |
PT10940 |
|
Capacity(L/h) |
200 |
430 |
958 |
1340 |
2660 |
4165 |
6660 |
10940 |
|
Tank volume(L) |
350 |
750 |
1580 |
2200 |
4050 |
6170 |
9610 |
15780 |
|
Aging time(h) |
1.0~1.5 |
1.0~1.5 |
1.0~1.5 |
1.0~1.5 |
1.0~1.5 |
1.0~1.5 |
1.0~1.5 |
1.0~1.5 |
|
Total power |
0.54 |
0.92 |
1.3 |
1.7 |
2.4 |
3.2 |
4.8 |
6.4 |
|
Empty weight(kg) |
250 |
350 |
480 |
560 |
790 |
1050 |
1200 |
1450 |
Features:
• High capacity mixing chamber.
• The unique, multi-zone activation chamber is designed to give energy values appropriate to the swelling and hydration needs of the chemical through this operation.
• Flow sensors, variable set-point for low water protection, auto restart.
• Single-phase continuous duty.
• Capacity ranging from 300L to 5000L.
Benefits:
• Reliable compliance with all statutory requirements.
• Fully-automatic operation with a minimun of staff and maintenance
• Flexible process design helps to adaptation to various concentration demands
• High process safety of water treatment.
Description:
The CPD type automatic polymer preparation and dosing unit is a delivery key auto-equipment, which can prepare and throw polymer solution continually. The raw material that is prepared may be the dry powder medicament or liquid state chemical medicament. It can complete the chemical combination and the admixture of the medicament continually and efficiently in order to obtain homogeneous and activated solutions. The equipment can be widely used in municiple sewage treatment plant, paper mill and the other technical treatment industry.
