100m3/H Water Treatment Lamella Thickener Plate Settler
Product Details:
| Place of Origin: | China |
| Brand Name: | CHENENG |
| Certification: | CE/ISO |
| Model Number: | SAL |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1pcs |
|---|---|
| Price: | negotiation |
| Packaging Details: | nude packing, bulk packed in wooden cases |
| Delivery Time: | 30 working days after received your payment |
| Supply Ability: | 15pcs per month |
|
Detail Information |
|||
| Product Name: | Lamella Clarifier | Application: | Water Treatment |
|---|---|---|---|
| Material: | CS Or SS | Standard: | ISO |
| Capacity: | 10-100m³/h | Structure: | Compact Connection |
| High Light: | water treatment lamella thickener,100m3/h lamella thickener,water treatment lamella plate settler |
||
Product Description
Best products Lamella clarifier /Inclined Tube SAL Cant-board Sedimentation Tank
Application
■ Municipal sewage: pre-treatment, back-wash treatment, primary treatment, secondary treatment and tertiary treatment, and sludge concentration; industrial application: industrial process water, industry chemistry – purification and concentration, paper pulp and paper-making plants, phosphorus removal in the steel industry, etc.
Advantages
■ Small occupied area: lengthen the cant-board to 1.5m, improve the separation efficiency of the sedimentator, and save the occupied area as much as 1.5-2 times;
■ Even water distribution: directly collect resistance water distribution and supernatant to ensure the balance of the water quality on each group of cant-boards
■ Good hydraulic conditions: have no hydraulic dead angle or vortex
■ Unblocking cant-board: the cant-board is at 60°, the board spacing is 8~10cm, and back-wash is set at the cant-board area
■ Be solid and durable: the separation sheet is made of 6mm hard PVC, embedded in the modular form, and has high strength and easy to wash and maintain
|
Model Parameter |
SAL5 | SAL10 | SAL20 | SAL30 | SAL40 | SAL50 | SAL60 | SAL80 | SAL100 |
| Water Treatment Capacity(m3/h) | 5 | 10 | 20 | 30 | 40 | 50 | 60 | 80 | 100 |
| Motor Power (kw) |
None |
0.55 | |||||||
| Sludge Scraper Velocity (m/min) | None | 2.26 | 2.1 | 2.3 | 2.5 | 2.55 | 2.64 | 2.82 | |
| Cant-board Quantity (pieces) | 10 | 15 | 38 | 46 | 50 | 56 | 58 | 60 | 64 |
| Cant-board Specification (mm) | 1060*1200 | 1350*1465 | 750*1600 | 900*1600 | 1050*1600 | 1100*1600 | 1150*1800 | 1200*2000 | 1300*2000 |
| Equivalent Weight Sedimentation Area (m2) | 6.36 | 14.83 | 22.8 | 33.12 | 42 | 49.7 | 60.03 | 72 | 83.2 |
| Equipment Length L (mm) | 2400 | 3000 | 3750 | 4050 | 4340 | 4525 | 4725 | 4975 | 5175 |
| Equipment Width W (mm) | 1340 | 1740 | 2220 | 2520 | 2820 | 3090 | 3190 | 3290 | 3490 |
| Equipment Height H (mm) | 3050 | 3200 | 4650 | 4650 | 4700 | 4900 | 5100 | 5330 | 5330 |
| Intake Pipe Diameter | DN80 | DN100 | DN125 | DN150 | DN200 | ||||
| Outlet Pipe Diameter | DN80 | DN100 | DN125 | DN150 | DN200 | ||||
| Sludge Discharge Pipe Diameter | DN150 | DN200 | |||||||
