100m3/H PVC Lamella Plate Separators , Lamella Inclined Plate Clarifier
Product Details:
| Place of Origin: | China |
| Brand Name: | CHENENG |
| Certification: | CE/ISO |
| Model Number: | SAL |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1pcs |
|---|---|
| Price: | negotiation |
| Packaging Details: | nude packing, bulk packed in wooden cases |
| Delivery Time: | 30 working days after received your payment |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 15pcs per month |
|
Detail Information |
|||
| Product Name: | Lamella Clarifier | Application: | Water Treatment |
|---|---|---|---|
| Material: | CS Or SS | Standard: | ISO |
| Capacity: | 10-100m³/h | Structure: | Compact Connection |
| High Light: | PVC Lamella Plate Separators,100m3/h Lamella Plate Separators,100m3/h lamella inclined plate clarifier |
||
Product Description
Pvc Pp Lamella Plate Separators, Tube Settler Separator Lamella Plate Clarifier
1. Inclined tube material: PVC,PE,PP ,inclined plate: carbon steel lining
2.Inclined tube cross section is regular hexagon, inclined plate cross section can be parallel-plate.
3. The cleaning water area height is 1.0-1.5m above the inclined pipe top, the water distribution zone below the bottom no less than 1.0-1.5m, mechanical discharge sludge, the water distribution zone height should more than 1.6m, convenient install and maintenance.
4. The Re number in water flow less than 500,Fr number is 10-3—10-5 in inclined pipe.
5. Inclined tube design flow rate is 1.0-4.0mm/s, inclined plate 10-20mm/s.
Specifications:
|
Type size |
Treatment Capacity |
Tank Length (mm) |
Tank Width (mm) |
Tank Height (mm) |
|
SAL-10 |
10m³/h |
2400 |
1200 |
3500 |
|
SAL-15 |
15 m³/h |
3000 |
1200 |
4000 |
|
SAL-20 |
20m³/h |
3000 |
1800 |
4000 |
|
SAL-35 |
35m³/h |
3400 |
1800 |
4500 |
|
SAL-65 |
65 m³/h |
4300 |
1800 |
5000 |
|
SAL-100 |
100m³/h |
4600 |
2700 |
5500 |
Appication:
1. the industrial sewage
2. the sanitary sewage
3. the coal mine pit sewage
4. the non-ferrous metal processin gwaste water
5. the power plant
6. the chemical industry, coal, electric poer, fat, machinery sewage treatment projects.
