Full Automatic Operation Dissolved Air Flotation For Palm Oil Recovery 1-100m³/H Capacity
Product Details:
| Place of Origin: | China |
| Brand Name: | CHENENG |
| Certification: | CE/ISO |
| Model Number: | SOR |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1pcs |
|---|---|
| Price: | negotiation |
| Packaging Details: | nude packing, bulk packed in wooden cases |
| Delivery Time: | 30 working days after received your payment |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 10pcs per month |
|
Detail Information |
|||
| Product Name: | Dissolved Air Flotation | Application: | Water Treatment |
|---|---|---|---|
| Material: | CS Or SS | Standard: | ISO |
| Capacity: | 1-100m³/h | ||
| High Light: | dissolved air flotation equipment,dissolved air flotation for water clarification |
||
Product Description
Full-automatic operation & Dissolved Air Flotation fo Palm oil recovery
Application
Large flow rate high concentration organic wastewater,as papermaking,printing and dyeing,textile,pharmacy,ferment etc wastewater.
Separation and recovery Oil & Grease in the wastewater,as oil exploitation and refine,biodiesel,machining,food processing and dining etc.
Swine and slaughter house wastewater treatment.
Manufacturing wastewater,as electroplate,spray wastewater.
Water deep purification,as river,scenic water and deep reuse water treatment etc.
Solid liquid separation of bio-treatment outflow.
Advantage
- Use microbubble generation technology.
- Use high-efficiency pressor jet dissolved air technology.
- Low investment,cost-effective.
- High treating efficiency,small footprint.
- Easy operation and simple management.
| Model | Capacity(m³/h) | Tank length(mm) | Tank width(mm) | Tank depth(mm) | Pump(kw) | Air compressor(kw) | Skimmer(kw) |
| SOR-1 | 0.5-1m³/h | 1500 | 955 | 1063 | 0.55 | 0.55 | 0.18 |
| SOR-3 | 2-3m³/h | 3000 | 2100 | 2300 | 0.75 | 0.55 | 0.37 |
| SOR-5 | 3-5m³/h | 3200 | 2300 | 2300 | 1.1 | 0.55 | 0.37 |
| SOR-10 | 5-10m³/h | 4200 | 2500 | 2500 | 1.5 | 0.75 | 0.37 |
| SOR-15 | 10-15m³/h | 4700 | 2800 | 2500 | 2.2 | 0.75 | 0.37 |
| SOR-20 | 15-20m³/h | 4700 | 3100 | 2500 | 2.2 | 0.75 | 0.37 |
| SOR-30 | 20-30m³/h | 5700 | 3400 | 2500 | 3.0 | 0.75 | 0.37 |
| SOR-40 | 30-40m³/h | 7200 | 3300 | 2500 | 5.5 | 0.75 | 0.37 |
| SOR-50 | 40-50m³/h | 7200 | 3800 | 2500 | 7.50 | 1.5 | 0.37 |
| SOR-60 | 50-60m³/h | 8200 | 3900 | 2500 | 7.50 | 1.5 | 0.37 |
| SOR-70 | 60-70m³/h | 9200 | 4100 | 2500 | 11.00 | 1.5 | 0.55 |
| SOR-80 | 70-80m³/h | 10200 | 4400 | 2500 | 11.00 | 1.5 | 0.55 |
| SOR100 | 80-100m³/h | 10200 | 4800 | 2500 | 15.00 | 2.2 | 0.55 |
