Slaughterhouse wastewater treatment DAF Dissolved Air Flotation unit for industries
Product Details:
| Place of Origin: | China |
| Brand Name: | CHENENG |
| Certification: | CE/ISO |
| Model Number: | SOR |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1pcs |
|---|---|
| Price: | negotiation |
| Packaging Details: | nude packing, bulk packed in wooden cases |
| Delivery Time: | 30 working days after received your payment |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 10pcs per month |
|
Detail Information |
|||
| Product Name: | Dissolved Air Flotation | Application: | Water Treatment |
|---|---|---|---|
| Material: | CS Or SS | Standard: | ISO |
| Capacity: | 1-100m³/h | ||
| High Light: | daf system water treatment,dissolved air flotation for water clarification |
||
Product Description
Feature of dissolved air flotation daf
1 Due to the characteristics of the manufacturing solutions,
it is high efficiency of the dissolved vapor.
2 the separation of the mechanism of tiny bubbles generator,
raw water, dissolved gas will water and medicine (all line hydrocyclone into) to make a rapid combination, release, flocculation, ascending and floating, tiny bubbles uniform, density, solutions to upper, ascending and floating rate stable zero speed, form the three-dimensional microcirculation state, ensure the tiny bubbles in waste and flocculation body full access, combined.
3 No matter in combination with process or have combination of floc properties, are not the external force and destroyed their combination, floc properties of floating stability.
Applications:
1. Abattoirs
2. Cheese processing
3. Container washing
4. Dairies
5. Food processing
6. Fish processing
7. Metal removal
8. Meat industry
9. Poultry processing
10. Pulp& paper
11. Small goods
12. Tanneries
13. Vegetable industries
Competitive Advantage:
|
True Dissolved Air Process |
Treated water from the base of the DAF is mixed with compressed air in a Dissolved Air contactor. At the entry to the DAF, the pressure is released to ensure production of uniformly sized micro-bubbles that are key to optimizing bubble attachment. |
|
Integrated chemical reaction tanks |
This DAF system can be manufactured with any number of chemical reaction tanks for upstream Ph control or coagulation. The reaction tank is constructed in stainless steel, with a retention time to suit each application. |
|
Skid-Mounted and Pre-Tested |
This DAF system is usually supplied as skid-mounted, pre-tested units to simplify installation. |
|
Bottom Sludge Removal |
For ease of cleaning, this DAF system are designed with a sloping base to allow any settled solid to be drained as a option. On larger DAF systems our unique hopper bottom is a cost-effective, proven method of automatically removing solids. |
