CBS Continuous Backwash Sand Filter System , Industrial Water Filters
Product Details:
| Place of Origin: | China |
| Brand Name: | CHENENG |
| Certification: | CE/ISO |
| Model Number: | CBS |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1pcs |
|---|---|
| Price: | negotiation |
| Packaging Details: | nude packing, bulk packed in wooden cases |
| Delivery Time: | 30 working days after received your payment |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 30pcs per month |
|
Detail Information |
|||
| Product Name: | Continuous Backwash Sand Filter | Application: | Water Treatment |
|---|---|---|---|
| Material: | CS Or SS | Standard: | ISO |
| High Light: | industrial water filters,sand filtration wastewater treatment |
||
Product Description
CBS Continuous Backwash Sand Filter System , Industrial Water Filters
Description:
The CBS continuous backwash sand filter is an up-flow, moving bed filter that is constructed with various media depths for different applications and configurations. Raw water enters near the bottom of the tank by means of a stainless steel water distributor, Suspended solids are filtered out as the raw water flows up through the media bed. As the filtrate reaches the top of the filter, it passes over the effluent weir and is discharged. A portion of the filtrate is diverted through the san washer and used for cleaning and transferring the waste solids.
The CBS continuous backwash sand filter employs a backwash rinse that is performed continually while the tank is processing water. An air lift pump, located at the center of the module draws the media from the bottom of the filter up into the wash box. As the media is released into the wash box, it falls into the sand scrubber where the filtered solids are separated from the sand.
From there, the filtrate carries the solids out as waste (backwash). The washed sand falls down onto the media bed for continued use.
Applications:
Municipal
- Suspended solids reduction
- Water reuse
- Denitrification and nitrification
- Chemical phosphorus removal
- Pretreatment to other processes
Industrial
- Metal finishing
- Backwash recovery
- Process water
- Cooling tower blowdown
- Steel mill scale
- Chemical processing
- Ideal for pretreatment in lieu of gravity filters
Competitive Advantage:
1. Automatically backwashes while filtering for continuous operation
2. High filtrate rates in a small footprint
3. Effectively filters otherwise hard-to-filter solids
4. Save energy and maintenance costs
5. Produces an uninterrupted treated water steam, with a minimal resultant waste stream for disposal or further treatment
