Multiphase pump DAF dissolved air flotation water treatment machine with ISO Approval
Product Details:
| Place of Origin: | China |
| Brand Name: | CHENENG |
| Certification: | CE/ISO |
| Model Number: | MPF |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1pcs |
|---|---|
| Price: | negotiation |
| Packaging Details: | nude packing, bulk packed in wooden cases |
| Delivery Time: | 30 working days after received your payment |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 10pcs per month |
|
Detail Information |
|||
| Product Name: | Dissolved Air Flotation | Application: | Water Treatment |
|---|---|---|---|
| Material: | CS Or SS | Standard: | ISO |
| Working Capacity: | 3-100m³/h | Structure: | Compact Connection |
| High Light: | dissolved air flotation equipment,daf system water treatment |
||
Product Description
Multiphase pump DAF dissolved air flotation water treatment machine with ISO Approval
Cheneng MPF Dissolved Air Flotation Clarifier is suitable for wastewater streams containing solids, oils, and greases, which are difficult to settle or have a tendency to float. With proper chemical conditioning we remove colloidal and emulsified materials. Complete pretreatment systems can be supplied.
Features
No need air compressor
High removal efficiency
Continuous operation
Application versatility
Ease of installation
Fully customizable
Applications
Pulp and paper
Food Processing
Chemical Processing
Textiles
Municipal
Algae Removal
Bakery Waste
Fiber Recovery
Paint Waste
Poultry Processing
Slaughter House Sewage
Specifications
|
Type size |
Treatment capacity |
Length (mm) |
Width (mm) |
Depth (mm) |
Pump power consumption (kw) |
Skimmer power consumption (kw) |
|
MPF-3 |
3m³/h |
2800 |
800 |
1900 |
1.1 |
0.37 |
|
MPF-5 |
5 m³/h |
3000 |
1000 |
1900 |
1.1 |
0.37 |
|
MPF-10 |
10 m³/h |
4000 |
1200 |
2100 |
2.2 |
0.37 |
|
MPF-15 |
15 m³/h |
4500 |
1500 |
2100 |
3.0 |
0.37 |
|
MPF-20 |
20 m³/h |
4500 |
1800 |
2100 |
3.0 |
0.37 |
|
MPF-30 |
30m³/h |
5500 |
2000 |
2100 |
4.0 |
0.37 |
|
MPF-40 |
40m³/h |
6000 |
2200 |
2100 |
4.0 |
0.37 |
|
MPF-50 |
50m³/h |
6000 |
2700 |
2100 |
4.0 |
0.37 |
|
MPF-60 |
60m³/h |
7000 |
2800 |
2100 |
5.5 |
0.37 |
|
MPF-70 |
70m³/h |
8000 |
3000 |
2100 |
5.5 |
0.55 |
|
MPF-80 |
80m³/h |
9000 |
3200 |
2100 |
11 |
0.55 |
|
MPF-100 |
100 m³/h |
9000 |
3600 |
2100 |
15 |
0.55 |
