Professional Daf Dissolved Air Flotation Equipment For Leather Factory Waste Water
Product Details:
| Place of Origin: | China |
| Brand Name: | CHENENG |
| Certification: | CE/ISO |
| Model Number: | ORF |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1pcs |
|---|---|
| Price: | negotiation |
| Packaging Details: | nude packing, bulk packed in wooden cases |
| Delivery Time: | 30 working days after received your payment |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 10pcs per month |
|
Detail Information |
|||
| Product Name: | Cavitation Air Flotation | Application: | Water Treatment |
|---|---|---|---|
| Material: | CS Or SS | Color: | As Request |
| Capacity: | 1-500m³/h | Function: | Producing Fresh Water |
| High Light: | dissolved air flotation equipment,dissolved air flotation for water clarification |
||
Product Description
Professional Daf Dissolved Air Flotation Equipment For Leather Factory Waste Water
Product Description
1. Description
Dissolved Air Floatation is mainly for solid-liquid or liquid-liquid separation. Large sum of micro bubbles produced by dissolving and releasing system adhere to solid or liquid particles with same density as waste water to make the whole float to the surface thus achieve the aim of solid-liquid or liquid-liquid separation.
2. Application
(1) Remove oil and TSS.
(2) Separate small particles and algae in groundwater.
(3) Recover valuable products in industrial sewage such as paper pulp.
(4) Act as secondary sedimentation tank to separate and concentrate suspended particles and sludge.
3. Features
(1) Large capacity, high efficiency and small occupying space.
(2) Compact structure, easy operation and maintenance.
(3) Silt expansion elimination.
(5) Aerate to the water while air floating, it has an obvious effect to the elimination of active agent and foul smell in water. Meanwhile, the increased dissolved oxygen provides a favorable condition to the follow-up process.
(6) It can achieve the best effect in adopting this method when disposing the water with lower temperature, lower turbidity and more algae.
Suitable area:
slaughtering, starch, pharmaceuticals, papermaking, printing and dyeing,
leather and tannery, petrochemical industry, domestic wastewater, etc.
III. CAF Specification
|
Type |
Treatment |
Tank |
Tank |
Tank |
Aerator |
Skimmer |
|
ORF-1 |
1m³/h |
1400 |
550 |
1100 |
0.37 |
0.18 |
|
ORF-3 |
3 m³/h |
2500 |
800 |
1300 |
1.5 |
0.37 |
|
ORF-5 |
5 m³/h |
2500 |
1000 |
1300 |
1.5 |
0.37 |
|
ORF-10 |
10 m³/h |
3000 |
1200 |
1300 |
2.2 |
0.37 |
|
ORF-15 |
15 m³/h |
4000 |
1200 |
1300 |
2.2 |
0.37 |
|
ORF-20 |
20m³/h |
5000 |
1200 |
1300 |
2.2 |
0.37 |
|
ORF-30 |
30m³/h |
5000 |
1600 |
1800 |
2.2 |
0.37 |
|
ORF-40 |
40m³/h |
6000 |
1600 |
1800 |
2.2 |
0.37 |
|
ORF-50 |
50m³/h |
6000 |
1800 |
1800 |
4.4 |
0.37 |
|
ORF-75 |
75m³/h |
7000 |
2400 |
1800 |
4.4 |
0.55 |
|
ORF-100 |
100m³/h |
8000 |
2400 |
1800 |
4.4 |
0.55 |
|
ORF-150 |
150 m³/h |
11500 |
2400 |
1800 |
6 |
0.55 |
|
ORF-200 |
200m³/h |
15000 |
2400 |
1800 |
9 |
0.55 |
|
ORF-300 |
300 m³/h |
15000 |
3100 |
1800 |
12 |
0.55 |
|
ORF-400 |
400m³/h |
17000 |
3600 |
1800 |
12 |
0.55 |
|
ORF-500 |
500m³/h |
21000 |
4500 |
1800 |
15 |
1.10 |
